Eclisse FD30 Single Pocket Door Kit – To Suit 100mm Thick Wall

This system is ideal for creating a seamless and space-saving entrance while ensuring fire safety compliance.

This system is approved for use with a range of CLIMADOOR, XL Joinery, Vaicaima and JELD-WEN FD30 44mm door panels, allowing for various design options.

PLEASE NOTE:

• Not all fire rated designs by the above manufacturers are suitable for use in this system, if you have a query as to whether a particular design is suitable, please get in touch with our sales team by emailing **EMAIL** or calling our Sales Centre during working hours.
• If setting out your studwork before delivery of your frame please note there is approximately an 8mm tolerance built into the height of these pocket door systems which you will need to take into account. Packers may be required to accommodate for this gap if you are unable to adjust the studwork above the system.
• In order to comply with the product's fire certificate, the frame should be installed at finished floor level.

For installations with a 100mm finished wall thickness, ECLISSE provides 8 standard door panel size options:

Key Features:

• Supplied with comprehensive fitting instructions,.
• Suitable for selected 44mm thick FD30 Fire Doors. The system has been tested to BS EN 1634-1:2008 standards for fire resistance at an independent UKAS-accredited testing laboratory, ensuring compliance with the latest fire safety regulations.
• Complete with specialised primed hardwood jamb kit with integrated architrave, and supplied with 15x4mm White Graphite-based Intumescent Strips for professional Approved Document B compliant finished system.
• Max door weight 100kg (220lbs)
• Self-centering anti-warp floor guide.
• Compatible accessories like flush pulls, soft-close, self-close and others. (Self-closing mechanism may be specified by your Building Inspector, it is always worth checking this prior to purchase).
• 15 year guarantee on the complete Eclisse steel pocket system and runners against manufacturing defects.

ECLISSE Sliding Pocket Door Systems offer a sleek, space-efficient solution for seamlessly integrating doors into your living spaces, combining functionality and design.

Optional Accessories (Sold separately):

• BIAS® soft-close with anti-slam
• BIAS® DS Bi-directional soft-close with anti-slam, self-closing mechanism
• E-motion linear motor for automatic open/close

PLEASE NOTE: When fitting flush pull handles, we recommend regulating the stop so the door protrudes from the pocket to avoid risk to fingers. If the door is adjusted to enter the pocket completely, we do not accept any liability.
